Sandvik CH865i Cone Crusher
Overview
Sandvik CH865i is a high capacity technologically advanced, mid-range cone crushers designed for crushing applications in mines or large sized quarries.
CH865i Stationary Cone Crusher
The crusher has a hydraulically supported main shaft which is supported at both ends. With a robust design, adjustable eccentric throw, a constant intake opening, they offer production flexibility and depending on crushing application, they perform up to 30% better compared to other crushers in their class.
With the Sandvik CH865i, the increased crushing force facilitates higher size reduction, resulting in a finer product size and less circulating load in closed circuits. It’s particularly beneficial for tertiary and pebble crushing applications.
They bring you a revolution in intelligent crushing. Connected via the My Sandvik portal, they offer 24/7 access to data generated by your connected Sandvik crusher fleet. Now you can make decisions based on facts, and clearly see areas where you can improve uptime and productivity. My Sandvik gives you access to manuals and an e-commerce platform for easily and efficiently buying and reordering wear and spare parts. It lets you track and trace parts online to make maintenance planning simpler.
The CH865i comes with the new generation Automation and Connectivity System (ACS) as standard. The system continuously monitors and optimizes crusher performance and controls the complete lubrication system, increasing uptime and reliability. It can automatically adjust crusher settings to compensate for crushing chamber wear– ensuring consistent product size. Hydroset™ and the advanced dump valve automatically provide overload protection to let tramp iron or other uncrushable material pass through.
Technical data
- Nominal capacity: 155 – 517 mtph (171 – 570 stph)
- Max. feed size: 123 mm (4.8 in.)
- Motor power: 500 kW (670 hp)
- Closed side setting (CSS) range: 10 – 44 mm (0.4 – 1.7 in.)
- Eccentric throw range: 30 – 70 mm (1.2 – 2.8 in.)
- Mantles (inner liners): A, B, EF, OB
- Concaves (outer liners): MF, F, EF, HR*
- Weight: 38,930 kg (85,826 lb)
- Automation: (ACS) Included
- Electric dump valve: Included
- Lubrication tank: Included
- Tank instrument monitoring system: Included
- Offline lubrication filtration unit: Included
Advantages
- Hydroset™ system provides safety and setting-adjustment functions
- Automation & Connectivity System (ACS) automatically adapts the crusher to varying feed conditions ensuring maximum 24/7 performance
- Unibody mainframe ensures optimal strength and less maintenance
- Lifting from above minimizes risks and allows for safer maintenance
- The electric dump valve system protects your crusher against unwanted pressure peaks greatly improving its performance and reliability
