Overview

Features and Benefits

• Hydraulic grizzly dump-over hopper is available for removing oversized material.
• Grizzly bypass chute with flop gate allows for either removal of the material that passes the grizzly deck onto an available cross-belt conveyor for stockpiling or for blending with the crushed material.
• Hydraulic lift and leveling system enables quick and easy set up and tear down.
• Totally self-contained, reliable diesel/electric or all-electric power. You won’t have to worry about hydraulic leaks and failures shutting you down.
• Built rock solid with proven technology and designed to last with minimal service and maintenance.
• Features unique two-step, 5’ grizzly deck to remove fines before crushing.
• Includes removable electrical control panel featuring pre-wired receptacles for radial stackers.
• Manage the feeder speed for complete control of the flow of material into the jaw with Variable Frequency Drive (VFD).
• Includes wireless remote control for the feeder shutdown and all motor stop.

Key Specifications

• Crusher:  2036
• Operating Length: 13.4 m / 43′ 10″
• Gross Weight: 30,400 kg / 67,000 lbs
• Travel Length: 12.1 m / 39’ 7”
• Travel Width: 2.6 m / 8’ 6”
• Travel Height:  4.1 m / 13’ 5”
• Feed Hopper Capacity: 8.4 m³ / 11 yd³
• Feed Hopper Capacity (Tons): 13.5 MT / 14.9 T
• Vibrating Feeder: 4.9 m x 0.8 m / 16′ x 32″
• Feeder Grizzly Deck: 1524 mm long 2 step / 60″ long 2 step
• Discharge Conveyor Width: 914 mm / 36″
• On-Plant Power Supply Diesel: 149 kW / 200 Hp diesel engine & 40 kW generator
• On-Plant Power Supply Electric: 75 kW / 100 Hp or 112 kW / 150 Hp all-electric power
