Overview

Features and Benefits

• Integrated 45” feed conveyor remains on for transport and eliminates the need for a separate feed conveyor.
• 6×20 three-deck, triple-shaft screen.
• Discharge chutes for top and middle decks can be mounted to discharge material to either side of the plant.
• Features screen service platforms for both sides of the screen that remain on for transport.
• Hydraulic lift and leveling system enables quick and easy set up and tear down with 4-leg version or available as a 6-leg version for complete run-on capabilities.
• Complete screen plant system. Just add radial stacking conveyors for stockpile capabilities.
• Produces up to four products simultaneously, three with absolute sizing, or return the oversized product for further reduction.
• The fines conveyor feeds onto a cross conveyor that can be mounted to discharge material on either side of the plant.
• The bottom deck cross conveyor can be mounted to discharge material to either side of the plant.
• Includes all-electric motors and electrical cords.
• Functions with controls built into our primary crusher for system integration or with an optional independent control system for stand-alone operation and easy integration into custom systems.

Key Specifications

• Screen: 6×20 Three-Deck, Triple-Shaft Screen
• Operating Length: 18.1 m / 59’ 6”
• Gross Weight: 27,200 kg / 60,000 lbs
• Travel Length: 16.9 m / 55’ 6”
• Travel Width: 3.6 m / 11’ 11”
• Travel Height: 4.1 m / 13’ 5”
• Bottom Screen Deck Cross Conveyor Width: 610 mm / 24”
• Under Screen Conveyor Width: 1524 mm / 60”
• Retractable Fines Cross Conveyor Width: 914 mm / 36” optional ; 1067 mm / 42″ optional
• Plant Feed Conveyor Width: 1143 mm / 45”
