Overview

The Sandvik QE442 Free Flow is a new addition to our premium range of scalpers. This version provides you with a versatile and highly efficient mobile solution for difficult to screen materials, without any of the plugging or blockages often experienced with traditional screens.

The Sandvik QE442 Free Flow features a heavy duty scalping screen which allows you to process large un-screened material on the rigid scalping top deck, whilst providing a fine screening solution on the dual motion lower deck. The Free Flow screen itself is hugely versatile, with a wide range of settings designed to suit your specific needs.

It is your ideal solution for processing materials such as soils, aggregates, ores, waste, biomass and other products with high moisture contents, whilst maintaining superior levels of productivity.

Sandvik QE442 Free Flow is designed and built for durability. It prioritizes operator safety and is fitted with feeder control and 2 speed radio tracking fitted as standard.

Advantages

• Aggressive Free Flow screen with wide range of adjustable throws and speeds enables the bottom deck to be tailored for numerous applications
• Easy operation through a unique color-coded control panel with sequential start / stop
• Hybrid “e” drive option with electric plug in available to run in diesel or electric mode
• Operator safety ensured with 2 speed radio tracking and feeder control as standard
• Massive stockpiling capability through integrated hydraulic conveyors
• Compatible for 2-way or 3-way split configurations

Technical data

• Screen Box 5.39 x 1.73 m / 17′ 8″ x 5′ 8″
• Capacity (up to): 400 mtph / 441 stph
• Engine C4.4 110 kW / 147 hp
• Transport Length 16.33 m / 53′ 7″
• Transport Width 3.20 m / 10′ 6″
• Transport Height 3.50 m / 11′ 6″
• Standard Weight: 37,587 kg / 82,865 lbs
• Hybrid Weight: 40,287 kg / 88,817 lbs
